Mains Powered Display Turntable With Slip Rings (Counterclockwise) (TTC500SR) 50kg Load Capacity
€656,34 inc VAT
€656,34 inc VAT
Downloads
Key Features of the TTC500SR
The TTC500SR is a mains-powered turntable unit specifically designed with slip rings to power illuminated revolving displays. This counterclockwise rotating display unit is perfect for businesses aiming to showcase their products with added lighting effects. With the capacity to rotate up to 50kg based on a balanced concentric load, the TTC500SR ensures that your displays are always in motion, captivating your audience.
Specifications and Details
Dimensions and Rotation:
The TTC500SR boasts a 230mm diameter turning plate, complemented by a 300mm base and a height of 100mm. It rotates at a consistent speed of 2.5 rpm counterclockwise. The unit is also fitted with slip rings, which supply power up to 4 amps to the display, making it ideal for powering display lighting.
Power and Safety:
Safety is paramount with the TTC500SR. The unit is designed with screw-fixing holes for secure placement and a rotating platform with mounting holes for the product display. Our mains-powered turntables, including the TTC500SR, are fitted with safety clutches to comply with EC regulations. It's crucial to note that display turntables should not be rotated manually, as this can damage the gears, especially if placed in a public area.
Important Considerations for Optimal Use
While the turntable is rated for up to 50kg, the size and balance of your display can significantly affect its performance. For instance, when used upside down, the weight loading is reduced to a maximum of 25kg.
The load must also be balanced so that counterweights might be necessary. We recommend purchasing a sample to test your specific revolving display before placing a bulk order. Additionally, this unit can be used for ceiling and wall-mounted applications, with a 25kg hanging load when ceiling-mounted. Perfect balance is essential for these applications.
Expert Advice and Support
At Coker Exhibition Systems, we pride ourselves on offering expert advice. If you have any queries about the TTC500SR or need guidance on the best turntable, please call us on 01256 768178. Our team is always here to help you get the most out of your display solutions. Please note that there's an expected 14-day production time for these units, plus delivery.
